GFEVT750-36高速熔斷器（25A-400A）750Vdc

[附件: Download]



Description

Design For DC Applications


  • Excellent DC Performance
  • Superior Cycling Capability
  • Low Watt Losses

Standards / Approvals:

  • Refer To UL 248.1/UL 248.13
  • IEC 60269.1/IEC 60269.4
  • Reach Declaration Available Upon Request
  • RoHS Compliant

Features & benefits

  • This product is a fuse designed for partial range protection.
  • It features low I2t, strong current-limiting capability, and high breaking capacity.
  • It is suitable for applications in industries such as rail transit, electric vehicles, and boats.
  • It can serve as backup protection after short-circuiting for energy storage systems, power systems, conductors, and other devices and equipment.

Fuse Ratings

Part No. Fuse Amps Breaking Capacity Average @50KA/750Vdc Power Loss (W) Installation torque
A2s Melting A2t Clearing 100%
GFEVT750-25A-36 25 50kA 32 96 8 11.0±1.0 N·m
GFEVT750-32A-36 32 50kA 46 138 9 11.0±1.0 N·m
GFEVT750-40A-36 40 50kA 81 254 10 11.0±1.0 N·m
GFEVT750-50A-36 50 50kA 148 490 13 11.0±1.0 N·m
GFEVT750-63A-36 63 50kA 310 1070 15 11.0±1.0 N·m
GFEVT750-80A-36 80 50kA 535 1890 18 11.0±1.0 N·m
GFEVT750-100A-36 100 50kA 870 3140 20 11.0±1.0 N·m
GFEVT750-125A-36 125 50kA 1450 5465 24 11.0±1.0 N·m
GFEVT750-160A-36 160 50kA 2740 10460 26 11.0±1.0 N·m
GFEVT750-200A-36 200 50kA 4560 18280 32 11.0±1.0 N·m
GFEVT750-225A-36 225 50kA 5400 22340 35 11.0±1.0 N·m
GFEVT750-250A-36 250 50kA 7520 32550 38 11.0±1.0 N·m
GFEVT750-315A-36 315 50kA 13230 58900 44 11.0±1.0 N·m
*GFEVT750-350A-36 *350 50kA 18145 78650 48 11.0±1.0 N·m
*GFEVT750-400A-36 *400 50kA 17500 84000 53 11.0±1.0 N·m
* If there are any requirements, please communicate with the original factory staff first.
  • DC Cold Resistance are measured at <10% of rated current in ambient temperature of 25℃；
